Headrest Height Adjustment |
|
Hold the handle of headrest to adjust the height of it.There are 5 positions with 1.97" range. |
|
The most suitable height could be achieved when one's scruff is fully supported by the headrest. |
Headrest Angle Adjustment |
|
Hold the headrest cushion to adjust the angle of it.There is 120o range adjustment. |
|
The best angle could be reached when one could move the neck naturally. |
Backrest Tilt Angle Adjustment |
|
Pull the single rod control lever completely backward and lean against back until a desired angle is achieved,and then return the lever to the original middle position to lock at an ideal angle.There are 4 positions with 25º range. |
|
The proper backrest angle can reduce the pressure on the spine. |
Backrest Quick or Slight Tilt Tension Adjustment |
|
Pull the lever outwards,open the tilt tension adjustment handle, and turn it forward or backward into a desired tension for quick tilt tension adjustment or close the handle and turn it forward or backward for slight tilt tension adjustment,and then close the handle and push the lever inwards to the original position to fix it. |
|
The synchro mechanism is ergonomically designed to enhance comfort and reduce strain.The back-to-seat adjustment/tilt is 3:1 ratio. |
